Hey guys, I just thought I'd post some pics of work that we have done in the last few weeks. Please enjoy the pics, and do not hesitate to ask about anything you are seeing!


S4 single turbo build. Shooting for 1000 hp.

Start with manifolds :











Passenger side :











Testing different size turbos now.

T3/T04B S-3, just to see ...







GT42R. Don't think so.







Comp Turbo CT43XX ... much better fit, and good for the desired power.





























Another S4 kit, using GT2871R turbos :













































2860s or 2871s are tight in there ...



















Custom oil return adaptors :



Next on the to do list : 4-point roll bar in this 2006 M3 CS :




Unfortunately, the way the forum resizes pics makes them look jagged and rough. PM for a link to full size pics!

as a tig welder that works mainly with stainless i must say you have some awesome welds. i barely see that kind of welde from guys with 20 years of experience.

Damn Markku! You are a talented artist. Anytime you put your mind to anything, you do it amazing! Good work dude!!

iron_cannibal said:
as a tig welder that works mainly with stainless i must say you have some awesome welds. i barely see that kind of welde from guys with 20 years of experience.
Click to expand...

Je suis soudeur aussi et bien que j ai commence a faire pas mal de Stainless Steel au Tig je dois dire la meme chose. Les soudures sont de TOP qualite.

est-ce que toutes les composantes (tuyau, v-band, etc) sont des composantes Vibrant?

superbe travail, on voit ça généralement des shop super hot aux states mais content de voir qu'on peut avoir la même qualité de travail au Québec.

curious but where is the wastegate on the first setup? I might just be glancing too fast i that case sorry ahead of time

awesome work though

That's all nice and awesome work, unfortunatly that's the only thing I've came to expect from you ever since you did my piping in RMRs stock room years ago... but now enough with the Audi and bring in my car again!!!
